Oil Fired Hot Water System uses oil to provide hot water for heating as well as to provide for the household's running water. In this hot water system, oil reserve tank injects oil to the water heater's combustion chamber at the bottom of the tank. This system is easy to operate along with fast installation. Oil Fired Hot Water System is usually either part of a central heat system that provides hot water for radiant heating as well as hot water for the household water system. This is also used for high capacity hot water systems for businesses that require large amounts of hot water.
SALIENT FEATURES :
ASCENT HOT WATER SYSTEM -TECHNICAL SPECIFICATIONS
Model | AT - 05 | AT - 10 | AT - 20 | AT - 40 | AT - 60 | AT - 100 |
Heat Output-kcal/h | 50,000 | 100,000 | 200,000 | 400,000 | 600,000 | 1,000,000 |
Temp.oC | 65oC to 90oC (Pressure system up to 160oC) | |||||
Flow -m3/h | 1.25 | 2.5 | 5·0 | 10·0 | 15·0 | 25·0 |
Thermal Efficiency % | 88+2% | | | | | |
Fuel (Light Oil) kg/h | 6 | 11 | 22 | 44 | 67 | 111 |
Fuel (heavy Oil) kg/h | - | - | 24 | 47 | 71 | 118 |
Connected Load - Kw | ||||||
Light Oil | 1.5 | 2.5 | 3.5 | 6·0 | 9·0 | 12·0 |
Heavy Oil | - | - | 6.5 | 9·0 | 15·0 | 21·0 |
Coil Volume in Ltrs. | 20 | 30 | 60 | 215 | 330 | 615 |
Mixing Tank Cap. Ltrs. | 500 | 1000 | 2000 | 3000 | 5000 | 10000 |
Inlet/Outlet Size - mm | 25 | 40 | 50 | 65 | 80 | 100 |
Dry weight of Boiler - kg | ||||||
Light Oil | 750 | 925 | 1050 | 2300 | 2750 | 4100 |
Heavy Oil | - | - | 1150 | 2400 | 2850 | 4200 |
Overall Dimensions - mm | ||||||
Height | 1600 | 2100 | 2300 | 2800 | 3300 | 3800 |
Length | 1200 | 1500 | 1600 | 1900 | 2200 | 2500 |
Width | 700 | 850 | 1100 | 1900 | 1950 | 2200 |
